Audiopipe 12" Subwoofer TS-PP2-12-D4 300W RMS Dual 4Ω

The Audiopipe TS-PP2-12-D4 is a 12-inch car subwoofer built for deep, accurate bass with 1000W peak and 300W RMS power handling.

Designed to upgrade a vehicle’s low-end performance, this TS-PP2-12-D4 delivers powerful bass from 29Hz up to 1.5kHz while maintaining thermal stability and durability. Its 2.5-inch, four-layer Kapton voice coil and 68 oz magnet give it the muscle to reproduce impactful lows without premature failure, and the polypropylene cone with a rubber surround helps balance stiffness and compliance for tight, musical response. The speaker ships individually and is suited for sealed or ported enclosures that match its mounting depth and impedance.

How loud and powerful will this subwoofer get in my car?

The TS-PP2-12-D4 provides high output potential with a 1000-watt peak (P.M.P.O.) and a sustained 300-watt RMS rating, making it capable of delivering strong transient punch and consistent low-frequency presence. Sensitivity of 86 dB ensures efficient conversion of amplifier power into audible bass.

• Peak power: 1000 W
• Continuous power: 300 W RMS
• Sensitivity: 86 dB for effective loudness per watt
• Frequency span: 29 Hz–1500 Hz for extended bass range

What construction features help it handle heat and heavy use?

Audio stress from high SPL sessions is managed by a 2.5-inch, four-layer Kapton voice coil which resists heat and maintains voice-coil integrity over prolonged playback. The heavy-gauge steel frame and large 68 oz motor assembly also contribute to stability and accurate cone control under load.

• 2.5" Kapton multi-layer voice coil for thermal endurance
• Rigid steel basket reduces resonance and distortion
• 68 oz magnet for stronger motor force and power handling
• PP cone with rubber surround for durability and consistent excursion

Will the subwoofer fit my installation and what wiring options does it offer?

Mounting depth for the TS-PP2-12-D4 is 5-5/8 inches (142 mm), so verify available enclosure or vehicle clearance before purchase. The unit is dual 4-ohm, providing flexible wiring choices — you can wire it alone for a 4-ohm load or combine multiple subs to achieve desired final impedance for your amplifier.

• Mounting depth: 5-5/8" (142 mm) — fits many compact enclosures
• Impedance: Dual 4 Ω voice coils for flexible wiring
• Sold individually to enable custom channel and enclosure builds
• Works in both sealed and ported boxes when tuned to spec

How will this subwoofer affect music clarity and bass control?

The combination of a polypropylene cone and rubber surround offers a balance of rigidity and damping that helps produce tight, controlled bass rather than loose boom. When paired with an appropriately matched amplifier and enclosure, it reproduces low-frequency details while minimizing unwanted distortion.

• PP cone for stiffness and clean transient response
• Rubber surround for extended reliability and linear excursion
• Wide frequency response captures both sub-bass and low-mid content
• Steel frame minimizes mechanical deformation at high power

Who is this for? The Audiopipe TS-PP2-12-D4 is ideal for car audio enthusiasts building a robust low-frequency system who need a cost-effective 12" driver that handles sustained power and heat. It suits DIY installers and professional shops creating sealed or ported enclosures for music and multimedia use where dependable bass, thermal resilience, and flexible wiring are important.
